| Part Number | Dimension(mm) | ||
| d | D | L1 | |
| AL12 | 12 | 62 | 42 |
| AL15 | 15 | 68 | 52 |
| AL20 | 20 | 75 | 57 |
| AL25 | 25 | 90 | 60 |
| AL30 | 30 | 100 | 68 |
| AL35 | 35 | 110 | 74 |
| AL40 | 40 | 125 | 86 |
| AL45 | 45 | 130 | 86 |
| AL50 | 50 | 150 | 92 |
| AL55 | 55 | 160 | 104 |
| AL60 | 60 | 170 | 114 |
| AL70 | 70 | 190 | 134 |
| AL80 | 80 | 210 | 144 |
| AL90 | 90 | 230 | 158 |
| AL100 | 100 | 270 | 182 |
| AL120 | 120 | 310 | 202 |
| AL150 | 150 | 400 | 246 |
| AL200 | 200 | 520 | 326 |
| AL250 | 250 | 610 | 396 |
